  • High brightness LEDs with integrated optics
  • Three colors showing the time of red, green and yellow light separately
  • LED diodes array scientifically and neatly, uniform brightness and wide view angle
  • Easy installation and maintenance
  • Moisture and dust tight seal
  • Surrounded by sun visor, effectively prevent water& dust
  • Color wires with connector for easy connection
  • The damage of a single LED diode would not affect the performance of the timer
  • Studying mode, can automatically detect the signal phase time and adjust the time displayed accordingly Short learning time, can study the new phase time after one complete cycle
  • Energy saving
  • Wide working voltage
  • Total Harmonic Distortion<20%
  • Open door from the mid-front, easy to install and check
Characteristics
Model Color Size (mm) Profile Voltage
VDC
LEDs Typical Wattage at 25℃ Luminance
(cd/㎡)
Typical Dominant Wavelength
(nm)
NBDJS188-RYG Red 500 square 12/24VDC 110/220VAC 560s <28w >400 625±5
Yellow 500 square 12/24VDC 110/220VAC 210s <10w >400 590±5
Green 500 square 12/24VDC 110/220VAC 384s <28w >400 505±2
